Products Description
High Strength SMA400BW Hot Rolled Corten Steel Plate is a weathering steel alloyed with copper (approximately 0.25%), chromium (approximately 0.5%), and nickel (approximately 0.3%).
The phosphorus content of this material is typically controlled between 0.04% and 0.10%, significantly enhancing atmospheric corrosion resistance while forming a stable, dense protective rust layer on the surface.
Its tensile strength typically ranges from 400 to 550 MPa, with a yield strength not less than 245 MPa and an elongation of approximately 21%.
Owing to these properties, High Strength SMA400BW Weathering Steel Plate is particularly suitable for flue gas emission systems, capable of withstanding corrosive environments containing sulfides and nitrogen oxides.
It is also frequently used in aesthetic architectural cladding and landscape structures due to the color transformation of its surface rust layer.
specifications
Thickness: 3mm--150mm
Width: 30mm--4000mm
Length: 1000mm--12000mm
Standard: ASTM EN10025 JIS GB
Chemical composition(mass fraction)(wt.%) of the SMA400BW
| C(％) | Si(％) | Mn(％) | P(％) | S(％) | Cr(％) | Ni(％) | Cu(%) |
| 0.18 | 0.15-0.65 | 1.25 | 0.035 | 0.035 | 0.45-0.75 | Max 0.05-0.30 | 0.30-0.50 |
Mechnical property for SMA400BW Corten steel Sheet
| Thickness (mm) | ||||||
| SMA400BW | ≤ 16 | > 16 ≤ 40 | > 40 ≤ 75 | > 75 ≤ 100 | > 100 ≤ 160 | > 160 |
| Yield strength (≥Mpa) | 245 | 235 | 215 | 215 | 205 | 195 |
| Tensile strength (Mpa) | 400-540 | |||||
Relate Steel Type
| Steel Type | Standard | Country Code | C(%) | V(%) | Si(%) | Mn(%) | P(%) | S(%) | Cr(%) | Ni(%) | Cu(%) |
| SMA400BW | 4269 | CNS | ≦0.18 | 0.15-0.65 | ≦1.25 | ≦0.035 | ≦0.035 | 0.45-0.75 | 0.05-0.30 | 0.30-0.90 | |
| SMA400BW | G3114 | JIS | ≦0.18 | 0.15-0.65 | ≦1.25 | ≦0.035 | ≦0.035 | 0.45-0.75 | 0.05-0.30 | 0.30-0.90 | |
| A588Gr.B | A588 | ASTM | ≦0.20 | 0.01-0.10 | 0.15-0.50 | 0.75-1.35 | ≦0.04 | ≦0.05 | 0.40-0.70 | ≦0.50 | 0.20-0.40 |
Relate Steel Type
| Steel Type | Yield stress (Mpa) | Tensile stress (Mpa) | Elongation (%) | Thick (mm) |
| SMA400BW | ≧345 | 400-540 | ≧23 | ≦16 |
| SMA400BW | ≧345 | 400-540 | ≧23 | ≦16 |
| A588Gr.B | ≧345 | ≧485 | ≧21 | ≦100 |
Application
JIS G3114 SMA400BW weathering steel plate is widely used across multiple fields due to its outstanding atmospheric corrosion resistance and excellent mechanical properties:
Air Preheaters and Economizers: Within power plant boiler systems, SMA400BW structural weathering steel plate can withstand long-term exposure to sulfur-containing flue gas environments, typically extending corrosion resistance lifespan by 2–4 times compared to ordinary carbon steel.
Railway Carriages: With a yield strength ≥245 MPa and tensile strength ranging from 400–550 MPa, it ensures structural stability under prolonged vibration and loading.
Container Manufacturing: Leveraging its weather resistance and weldability, SMA400BW-fabricated container exteriors maintain service life exceeding 10 years in coastal high-salt-fog environments.
Bridge Construction: Compared to painted steel, bridges using SMA400BW weathering sheet reduce maintenance costs by approximately 30–50%, making it particularly suitable for small-to-medium span bridges and pedestrian bridges.
Architectural Engineering: Its surface forms a dense rust layer approximately 50–100 μm thick, offering strong protection while developing a natural rust-red patina. It is commonly used for curtain walls, landscape components, and exterior facade decoration.
Contact now to get SMA400BW Quote
Packing and shipping
📦 Packing
By steel strips in bundles
By wooden pallet
Standard export seaworthy packing
According to client's requirement
🚢 Shipping
By LCL → for material less than 10 tons, max length 11.8M
By FCL 20ft container → max weight 25–26 tons, max length 6M
By FCL 40ft container → max weight 25–26 tons, max length 12M
By Bulk Vessel → for large qty (200 tons+), over-width & over-length material
By Air → for urgent request material
By Truck → for domestic transportation
By Train → for neighboring inland countries
⏱ Delivery
5–7 days → for stock available materials
10–15 days → for simple processing materials
20–35 working days → for indent material
